Nimble kit
Part number: C110K
Description
Entry-level open/close zone control kit using the C110MC basic CPU and C110WC push button wall controller. No temperature sensor support — zones are open/close only. No AC unit interface module included.
Installation guide
No installation guide available for this part.
Specifications
| Entry | Description |
|---|---|
| — | — |
Included in
| Part number | Description |
|---|---|
| C110MC | Basic CPU |
| CT24ACE | 24VAC power supply |
| CFC25S | 25m Cat5e cable |
| C110WC | Push button wall controller |
| STICKERS | Room name labels for push button controller |
Related parts
Documents
No documents available for this part.
Troubleshoot guide
Read more
Zones are not opening or responding
- Move the zone motor cable to a different unused port on the C110MC
- Check all zone motors are connected to consecutive ports starting at Zone 1
- Verify the CT24ACE is powered and outputting ~24VAC
Wall controller not responding
- Check the Cat5e cable between the C110WC and the C110MC iZone Net port
- Try a different iZone Net port on the C110MC
Firmware history
No firmware history — this part contains no embedded software.
